Commercial Panel Profiles



Precision Rib

  • 36” Panel Coverage with 12” on centers 1 1/8”  high ribs
  • Available in 26 gauge
  • Available in galvanized G60, G90 and galvalume
  • Custom cut lengths to the fraction of an inch (max. length 40’-0”)
  • For lengths over 40’-0” contact LCS
  • 1:12 min roof slope
  • Can be applied to either solid substrate or open framing
  • 40 year paint warranty
  • Available in all colors
  • Made from 32% recycled material

Available with Dripstop




PBR Panel

  • 36” Panel Coverage with 12” on centers 1 1/4” high ribs
  • Available in 26 gauge
  • Available in galvanized G60, G90 and galvalume
  • Custom cut lengths to the fraction of an inch (max. length 40’-0”)
  • For lengths over 40’-0” contact LCS
  • 1:12 min roof slope
  • Can be applied to either solid substrate or open framing
  • 40 year paint warranty
  • Available in all colors
  • Made from 32% recycled material

Available with Dripstop




Drain Rib Panel

  • 36” Panel Coverage with 3” on centers 1/2” high ribs
  • Available in 29 and 26 gauge
  • Available in galvanized G60, G90 and galvalume
  • Custom cut lengths to the fraction of an inch (max. length 40’-0”)
  • For lengths over 40’-0” contact LCS
  • 3:12 min roof slope
  • Can be applied to either solid substrate or open framing
  • 40 year paint warranty
  • Available in all colors
  • Made from 32% recycled material




Snap Lock

  • 12” and 16” Panel Coverage
  • Available in 26 gauge galvalume
  • Custom cut lengths to the fraction of an inch (max. length 35’-0”)
  • For lengths over 35’-0” contact LCS
  • 3:12 min roof slope
  • It is not recommended to install over open framing
  • UL 580 Class 90 uplift rating
  • UL 790 Class A fire resistance rating
  • UL 2218 Class 4 hail impact resistance
  • 40 year paint warranty
  • Available in all colors
  • Made from 32% recycled material
